Briggs & Stratton Vertical Engine 5 TP 140cc 7/8" x 3-5/32" #9P602-0139
Replaces 9M902-0015, 10T802-0015 4hp Briggs Sprint
Briggs 5 Torque Power Engine
Briggs 5 Torque Power Engine
140cc
7/8" x 3-5/32" keyed shaft.
Compliance engine.
Universal replacement engine for Snapper, MTD, Murray,
AYP, Noma, and other rotary mowers.
Model 9P602-0139.
20 lbs
09P602-0139-F1
Engine Specifications
| SKU | 09P602-0139-F1 |
| Model/Type/Trim | 09P602-0139-F1 |
| Air Cleaner | Foam |
| Carburetor | Primer - Simple System |
| Casing Clamp | Without |
| Controls | Fixed Speed |
| Crankshaft | Straight 7/8" Dia - 3.156" PTO |
| Emissions Certification | EVAP/EXH/EU |
| Engine Base | Standard (Non Flange Mount) |
| Engine Package | 500E Series |
| Engine Sold In | United States |
| Engine Speed | 3200 +/- 0100 RPM - No Load |
| Flywheel | Light - Aluminum |
| Fuel Cap | EVAP Black Tether |
| Label Power | Without, OEM to Install |
| Muffler Guard | Stamped |
| Oil Dipstick | In Cylinder |
| Rewind Position | 5:30 |
Technical Specifications
| Model Series | 09P6 |
| Power Lbs/Ft of Torque | 5 |
| Engine Series | 500 |
| Displacement | 140 |
| Oil Capacity | 16 oz (0.5 l) |
| Valve Configuration | OHV |
| Flywheel Torque | 60 lb/ft (81.5 Nm) |
| Governor Arm Torque | 30 lb/in (3.5 Nm) |
| Plug Gap | 0.02 in (0.50 mm) |
| Intake Valve | .004-.008 in (.10-.20 mm) |
| Exhaust Valve | .004-.008 in (.10-.20 mm) |
| Air Gap | .006-.014 in (.15-.36 mm) |
| Flywheel Puller Part | 19619 |
| Flywheel Holder Part | 19619 |
| Connecting Rod Torque | 100 lb/in (11.5 Nm) |
| Sump Torque | 85 lb/in (9.5 Nm) |
| Head Torque | 140 lb/in (16.0 Nm) |
| Top No Load (rpms) | 3200 +/- 0100 RPM - No Load |
$59.70
Original: $199.00
-70%Briggs & Stratton Vertical Engine 5 TP 140cc 7/8" x 3-5/32" #9P602-0139—
$199.00
$59.70
Description
Replaces 9M902-0015, 10T802-0015 4hp Briggs Sprint
Briggs 5 Torque Power Engine
Briggs 5 Torque Power Engine
140cc
7/8" x 3-5/32" keyed shaft.
Compliance engine.
Universal replacement engine for Snapper, MTD, Murray,
AYP, Noma, and other rotary mowers.
Model 9P602-0139.
20 lbs
09P602-0139-F1
Engine Specifications
| SKU | 09P602-0139-F1 |
| Model/Type/Trim | 09P602-0139-F1 |
| Air Cleaner | Foam |
| Carburetor | Primer - Simple System |
| Casing Clamp | Without |
| Controls | Fixed Speed |
| Crankshaft | Straight 7/8" Dia - 3.156" PTO |
| Emissions Certification | EVAP/EXH/EU |
| Engine Base | Standard (Non Flange Mount) |
| Engine Package | 500E Series |
| Engine Sold In | United States |
| Engine Speed | 3200 +/- 0100 RPM - No Load |
| Flywheel | Light - Aluminum |
| Fuel Cap | EVAP Black Tether |
| Label Power | Without, OEM to Install |
| Muffler Guard | Stamped |
| Oil Dipstick | In Cylinder |
| Rewind Position | 5:30 |
Technical Specifications
| Model Series | 09P6 |
| Power Lbs/Ft of Torque | 5 |
| Engine Series | 500 |
| Displacement | 140 |
| Oil Capacity | 16 oz (0.5 l) |
| Valve Configuration | OHV |
| Flywheel Torque | 60 lb/ft (81.5 Nm) |
| Governor Arm Torque | 30 lb/in (3.5 Nm) |
| Plug Gap | 0.02 in (0.50 mm) |
| Intake Valve | .004-.008 in (.10-.20 mm) |
| Exhaust Valve | .004-.008 in (.10-.20 mm) |
| Air Gap | .006-.014 in (.15-.36 mm) |
| Flywheel Puller Part | 19619 |
| Flywheel Holder Part | 19619 |
| Connecting Rod Torque | 100 lb/in (11.5 Nm) |
| Sump Torque | 85 lb/in (9.5 Nm) |
| Head Torque | 140 lb/in (16.0 Nm) |
| Top No Load (rpms) | 3200 +/- 0100 RPM - No Load |
