Kohler Command Pro 22.5 HP 674cc Engine 1-1/8" x 4" #CV680-3023
23 hp Command Pro
1-1/8" x 4" keyed shaft, tapped 7/16" with 1/4" keyway.
1-1/8" x 4" keyed shaft, tapped 7/16" with 1/4" keyway.
Scag Tiger Cub replacement engine
12 Volt Electric Start w/alternator
HD Cannister Air Cleaner
less muffler, less fuel tank
Remote Engine Control
2 Year Warranty
CV680-3023
106 lbs
Engine Type:
4-cycle, gasoline, OHV, cast iron cylinder liners, aluminum block
Model |
Command PRO CV680 |
| Max Power @3600 RPM hp (kW) | 23 (17.2) |
| Displacement cu in (cc) | 41.1 (674) |
| Bore in (mm) | 3.2 (80) |
| Stroke in (mm) | 2.6 (67) |
| Peak Torque @ Maximum lbs ft (Nm) | 40.2 (54.5) |
| Compression Ratio | 8.5:1 |
| Dry Weight lbs (kg) | 90 (41) |
| Oil Capacity U.S. quarts (L) | 2.0 (1.9) |
| Lubrication | Full pressure w/full-flow filter |
| Dimensions L x W x H in | 21.2 x 17.7 x 14.3 |
* Length is blower housing to air cleaner. Width is spark plug to spark plug. Height is top of air cleaner cover to mounting feet.
Kilowatt (kW) and horsepower (HP) specifications for Kohler general purpose engines are calculated pursuant to the Society of Automotive Engineers (SAE) J1940 for horsepower ratings - calculated with the air cleaner and muffler removed, per the SAE standard. Actual engine horsepower is lower and affected by, but not limited to, accessories (air cleaner, exhaust, charging, cooling, fuel pump, etc.), application, engine speed and ambient operating conditions (temperature, humidity and altitude). The reason for this standard is to provide consistent measurement to customers who may want to control the intake and exhaust features of the engine. It is important to note that the power output of all Kohler engines is always as advertised. For more information, contact Kohler Co. Engine Engineering Department. Kohler Co. reserves the right to change product specifications,designs and standard equipment without notice and without incurring obligation.
$839.70
Original: $2,799.00
-70%Kohler Command Pro 22.5 HP 674cc Engine 1-1/8" x 4" #CV680-3023—
$2,799.00
$839.70
