Kawasaki FX Series are compact, 90-degree V-twin engines which feature hemispherical combustion chambers and overhead V-valve technology that helps ensure low emissions, high power, and smooth operation. Other features include a twin barrel, internally vented carburetor with fuel shut-off solenoid, large capacity fuel pump, and dual stage canister air filter.

Forced Air-Cooled V-twin 4-cycle Vertical Shaft OHV Gasoline Engine

23.5hp Kawasaki OHV
1-1/8" x 4-5/16" shaft, tapped 7/16" with 1/4" keyway.

Electric start, 15amp alternator.

Less fuel tank
Seperate choke & throttle

Less Muffler
Heavy Duty Dual Stage Canister Air Filter

High Efficiency Oil Cooler
Large Capacity Fuel Pump
Replacement engine for commercial zero turns and riding mowers.

Model FX730V-CR00 (Replaces FX730V-DS00.FX730V-FS00,FX730V-AR00).

FEATURES:  Overhead v-valve 90° V-twin High performance pressurized lubrication Electronic spark ignition Automatic compression release Internally vented carburetor Rotating grass screen Dual stage canister air filter Cast-iron cylinder liners Metal engine cover Heavy-duty shift-type starter

SPECIFICATIONS DISPLACEMENT 726cm3 (44.3cu. in.) NUMBER OF CYLINDERS 2 BORE X STROKE 3.1 x 3.0 in. (78 x 76mm) COMPRESSION RATIO 8.2:1 OIL CAPACITY 2.2U.S. qt (2.1liters) MAXIMUM POWER 23.5hp (17.5kW) at 3,600rpm MAXIMUM TORQUE 39.9ft lbs (54.1N·m) at 2,400RPM DRY WEIGHT 102.7lbs (46.6kg)

Kawasaki Mufflers (not included)

Kawasaki 726cc V-Twin Muffler for Riding Mowers #KAWV726

Kawasaki 726cc Engine Oil Filter Side Muffler Kit #KAW726MUFOF

Kawasaki FS/FX 726cc Engine Muffler #KAW726MUFZTRSS
