Kawasaki Vertical 31 HP 999cc V-Twin OHV Engine ES 15amp 1-1/8" x 4-5/16" #FX921V-HS04

Kawasaki Vertical 31 HP 999cc V-Twin OHV Engine ES 15amp 1-1/8" x 4-5/16" #FX921V-HS04


Kawasaki FX Series are compact, 90-degree V-twin engines which feature hemispherical combustion chambers and overhead V-valve technology that helps ensure low emissions, high power, and smooth operation. Other features include a twin barrel, internally vented carburetor with fuel shut-off solenoid, large capacity fuel pump, and dual stage canister air filter.

Forced Air-Cooled V-twin 4-cycle Vertical Shaft OHV Gasoline Engine
34hp Gross HP now rated Kawasaki Critical 31HP Rating
31hp Kawasaki OHV
1-1/8" x 4-5/16" shaft, tapped 7/16" with 1/4" keyway.
Electric start, 15amp alternator.
Less fuel tank
Seperate choke & throttle
Less Muffler
Heavy Duty Dual Stage Canister Air Filter
High Efficiency Oil Cooler
Large Capacity Fuel Pump
Replacement engine for commercial zero turns and riding mowers.
Model FX921V-HS04 (Replaces FX921V-DS04).

FEATURES:

  • Overhead v-valve
  • 90° V-twin
  • High performance lubrication system
  • Electronic spark ignition
  • Automatic compression release
  • Three valves per cylinder
  • High efficiency oil cooler
  • Rotating grass screen
  • Dual stage canister air filter
  • Cast-iron cylinder liners
  • Metal engine cover
  • Heavy-duty shift-type starter
  • Twin barrel, internally vented carburetor with fuel shut-off solenoid
SPECIFICATIONS
DISPLACEMENT
999cm3 (61.0cu. in.)
NUMBER OF CYLINDERS
2
BORE X STROKE
3.5 x 3.15 in. (89.15 x 80mm)
COMPRESSION RATIO
8:4:1
OIL CAPACITY
1.8U.S. qt (1.7liters)
MAXIMUM POWER
31.0hp (23.1kW)
at 3,600rpm
MAXIMUM TORQUE
54.3ft lbs (73.6N·m)
at 2,400RPM
DRY WEIGHT
138.0lbs (62.6kg)

Kawasaki Mufflers (not included)

Kawasaki FS/FX 999cc Engine Muffler #KAW999MUFZTRSS
Kawasaki 999cc Engine Oil Filter Side Muffler Kit #KAW999MUFOF
$869.70

Original: $2,899.00

-70%
Kawasaki Vertical 31 HP 999cc V-Twin OHV Engine ES 15amp 1-1/8" x 4-5/16" #FX921V-HS04—

$2,899.00

$869.70
Product image 1
Product image 2
Product image 3
Product image 4
Product image 5
Product image 6

Description


Kawasaki FX Series are compact, 90-degree V-twin engines which feature hemispherical combustion chambers and overhead V-valve technology that helps ensure low emissions, high power, and smooth operation. Other features include a twin barrel, internally vented carburetor with fuel shut-off solenoid, large capacity fuel pump, and dual stage canister air filter.

Forced Air-Cooled V-twin 4-cycle Vertical Shaft OHV Gasoline Engine
34hp Gross HP now rated Kawasaki Critical 31HP Rating
31hp Kawasaki OHV
1-1/8" x 4-5/16" shaft, tapped 7/16" with 1/4" keyway.
Electric start, 15amp alternator.
Less fuel tank
Seperate choke & throttle
Less Muffler
Heavy Duty Dual Stage Canister Air Filter
High Efficiency Oil Cooler
Large Capacity Fuel Pump
Replacement engine for commercial zero turns and riding mowers.
3 year consumer from Kawasaki.
Model FX921V-HS04 (Replaces FX921V-DS04).

FEATURES:

  • Overhead v-valve
  • 90° V-twin
  • High performance lubrication system
  • Electronic spark ignition
  • Automatic compression release
  • Three valves per cylinder
  • High efficiency oil cooler
  • Rotating grass screen
  • Dual stage canister air filter
  • Cast-iron cylinder liners
  • Metal engine cover
  • Heavy-duty shift-type starter
  • Twin barrel, internally vented carburetor with fuel shut-off solenoid
SPECIFICATIONS
DISPLACEMENT
999cm3 (61.0cu. in.)
NUMBER OF CYLINDERS
2
BORE X STROKE
3.5 x 3.15 in. (89.15 x 80mm)
COMPRESSION RATIO
8:4:1
OIL CAPACITY
1.8U.S. qt (1.7liters)
MAXIMUM POWER
31.0hp (23.1kW)
at 3,600rpm
MAXIMUM TORQUE
54.3ft lbs (73.6N·m)
at 2,400RPM
DRY WEIGHT
138.0lbs (62.6kg)

Kawasaki Mufflers (not included)

Kawasaki FS/FX 999cc Engine Muffler #KAW999MUFZTRSS
Kawasaki 999cc Engine Oil Filter Side Muffler Kit #KAW999MUFOF
